Control Valve Seat Leakage Test

CONTROL  Valve Seat Leakage Testing Bench

(2’’-12’’ DN50-DN300)

Key Features:

● Designed to test Gate,Globe,Check,Ball and Control Valves

● Size range: 2’’-12’’ DN50-DN300

● Pressure range: Class 150-Class2500 PN16-PN420

( Pressure to be confirmed as different customers require different pressure ,

customization services available )

● Hydraulic Clamping system with three jaws, by means of clamping flanges

with blind flange adaptors ensure the positive seals of the valve flanges.

● Left work table is movable

● With Dwyer Flow meter

● Stainless steel tubes and pipelines available

● With interlock functions for safety

● Testing fluid by water or air ,water with a corrosion inhibitor,

according to international valve testing& Inspection standard like FCI 70-2 etc

● Recycle water tanks

● Air driven liquid booster pump(Maximator or Haskel)

● Data acquisition system is available, including PLC,Touch screen,

Printer,with test graphs & reports.

We can customize the machine for you, please send all your details to info@dorytestbench.com
