YFJ-B600 12''-24'' Valve Testing

  • YFJ-B600 Flanged Valves Pressure Test Bench
YFJ-B600 Flanged Valves Pressure Test Bench

YFJ-B600 Flanged Valves Pressure Test Bench

  • Valve Types: Gate/Globe/Check/Ball/Plug Valves etc
  • Size Range: 12''-24'' DN300-DN600
  • Pressure Range: Class 150-Class1500
  • Valve End Type: Flanged RF/RTJ
  • Product description: Equiped with Low Pressure Pump/High Pressure Pump Hydraulic Systsem,Electrical Control System
  • INQUIRY

YFJ-B600 Hydrostatic Valve Testing Bench

(12’’-24’’ DN300-DN600)


Key Features:

Designed to test Gate,Globe,Check,Ball and Control Valves

Size range: 12’’-24’’ DN50-DN600

Pressure range: Class 150-Class2500 PN16-PN420

( Pressure to be confirmed as different customers require different pressure ,

customization services available )

Hydraulic Clamping system with three jaws, by means of clamping flanges

with blind flange adaptors ensure the positive seals of the valve flanges.

Left work table is movable

Stainless steel tubes and pipelines available

With interlock functions for safety

Testing fluid by water or air ,water with a corrosion inhibitor,

according to international valve testing& Inspection standard like API598,

API6D,MSS-SP-70,ASME B16.34,MSS SP-85,FCI 70-2 etc

Recycle water tanks

Air driven liquid booster pump(Maximator or Haskel)

Data acquisition system is available, including PLC,Touch screen,

Printer,with test graphs & reports.



We can customize the machine for you, please send all your details to info@dorytestbench.com
